SPECIFICHE:
FEATURES:
PSI | CFM | A | BAR | LPM | A |
---|---|---|---|---|---|
0 | 1.80 | 12 | 0 | 51.0 | 12 |
10 | 1.75 | 14 | 1.0 | 47.6 | 15 |
20 | 1.60 | 16 | 2.0 | 43.3 | 17 |
30 | 1.52 | 17 | 3.0 | 38.2 | 18 |
40 | 1.39 | 18 | 4.0 | 34.0 | 19 |
50 | 1.27 | 19 | 5.0 | 30.5 | 20 |
60 | 1.18 | 19 | 6.0 | 28.1 | 21 |
70 | 1.09 | 20 | 7.0 | 26.4 | 22 |
80 | 1.04 | 20 | 8.0 | 25.0 | 23 |
90 | 0.97 | 21 | 9.0 | 23.0 | 22 |
100 | 0.94 | 22 | 10.0 | 21.0 | 21 |
110 | 0.90 | 23 | |||
120 | 0.86 | 23 | |||
130 | 0.81 | 22 | |||
140 | 0.76 | 21 | |||
150 | 0.72 | 20 |
31″ X 10.5″ | FILL RATE |
---|---|
0 to 30 PSI | 4 min. 05 sec. (±10 sec.) |
15 to 30 PSI | 2 min. 10 sec. (±05 sec.) |
33″ X 12.5″ | FILL RATE |
0 to 30 PSI | 5 min. 30 sec. (±15 sec.) |
15 to 30 PSI | 2 min. 50 sec. (±05 sec.) |
35″ X 12.5″ | FILL RATE |
0 to 30 PSI | 6 min. 55 sec. (± 15 sec.) |
15 to 30 PSI | 3 min. 30 sec. (± 10 sec.) |
37″ X 12.5″ | FILL RATE |
0 to 30 PSI | 7 min. 56 sec. (± 15 sec.) |
15 to 30 PSI | 4 min. 09 sec. (± 10 sec.) |
